Product Name: Thermal Printhead
Model : X40 X45 53mm
Category: Markem Printhead
Part Number: ENM10104790
Delivery Time: 1-3 days
Warranty:3 months/30km
The ENM10104790 is a 53mm OEM thermal printhead for the Markem-Imaje SmartDate X40 and X45 Thermal Transfer Overprinting (TTO) coders — two of the most widely deployed flexible film coding systems in food, beverage, pharmaceutical, and personal care packaging lines worldwide. At 300 DPI resolution and print speeds up to 600 mm/s, this printhead delivers the consistent, high-quality coding that production environments depend on for compliance, traceability, and brand integrity.
| Parameter | Specification |
|---|---|
| OEM Part Number | ENM10104790 |
| Compatible Printers | Markem-Imaje SmartDate X40, SmartDate X45 |
| Print Width | 53 mm |
| Print Resolution | 300 DPI (12 dots/mm) |
| Print Technology | Thermal Transfer Overprinting (TTO) |
| Max Print Speed | Up to 600 mm/s |
| Max Throughput | Up to 220 packs/min at 300 DPI |
| Printer Configurations | Intermittent and continuous motion |
| Typical Substrates | Flexible films, foils, laminates, polyester, polypropylene |
| Warranty | 3 months |
| Delivery Time | 1–3 business days |
The ENM10104790 printhead is designed for the following Markem-Imaje SmartDate coders:
⚠️ Important — verify your part number before ordering.
Multiple 53mm 300 DPI printheads exist for the SmartDate X40/X45 platform, with different OEM part numbers including ENM10104642, ENM10104790, ENM10053339, and 10042449. These may reflect different hardware revisions or regional supply variants. Always cross-reference the part number printed on your existing printhead before ordering. If you cannot locate the number on the unit, check your printer’s spare parts catalogue or contact us — we will confirm the correct part for your specific machine serial number and firmware version.
Thermal Transfer Overprinting is fundamentally different from label printing. In a TTO coder, the printhead presses a narrow ribbon against flexible packaging film at high speed — often while the film is moving continuously on a form-fill-seal (FFS) or flow-wrap machine. At 300 DPI, the SmartDate X40/X45 can print sharp text, barcodes (Code 128, Data Matrix, QR), logos, and regulatory compliance information — including lot numbers, best-before dates, and ingredient declarations — directly onto primary packaging film without the need for pre-printed labels.
The SmartDate X45 supports print speeds from 30 mm/s up to 600 mm/s, covering intermittent motion applications (flow wrap, pillow pack) and continuous motion lines (horizontal FFS) at up to 220 packs per minute. The printhead is integral to maintaining this speed range without dot dropout, smearing, or registration errors — making OEM component quality essential in high-throughput environments.
The SmartDate platform is designed for hygienic environments with IP-rated enclosures and wash-down tolerant construction. The printhead operates in the temperature and humidity conditions typical of chilled food production and pharmaceutical clean rooms. Using a genuine OEM printhead ensures the thermal energy curve, dot density, and ribbon tracking characteristics match the coder’s original calibration — preventing quality deviations that could trigger compliance failures or product recalls.
This is a 100% genuine Markem-Imaje OEM printhead bearing part number ENM10104790. It is not a compatible or third-party equivalent. Every unit is backed by a 3-month warranty covering manufacturing defects under normal operating conditions.
TTO printheads on high-speed packaging lines undergo more mechanical stress than standard label printer printheads — the printhead engages and releases against the packaging film thousands of times per shift. These practices will significantly extend service life:
The SmartDate X40/X45 is most commonly found in:
We ship globally with protective packaging and full customs documentation, typically within 1–3 business days of order confirmation. Our team has hands-on experience with Markem-Imaje SmartDate coders and can help verify the correct printhead part number for your machine before you order. We also supply TTO ribbons and consumables for the full SmartDate range, and offer volume pricing for packaging line operators, OEM integrators, and maintenance service providers.
Q1: What is the difference between ENM10104790 and ENM10104642?
Both are 53mm 300 DPI OEM printheads for the SmartDate X40 and X45, but they carry different part numbers, which typically indicates a hardware revision or a regional supply variant issued by Markem-Imaje. Always match the part number on your existing printhead exactly. If you are unsure, contact us with your printer’s serial number and we will identify the correct unit.
Q2: Can I use this printhead on the SmartDate X60 or X65?
No. The X60 and X65 use a different 53mm or 128mm printhead with a different mounting interface and connector configuration. The ENM10104790 is designed exclusively for the X40 and X45 platforms. Contact us for X60/X65 printhead availability.
Q3: Is this compatible with both intermittent and continuous motion configurations?
Yes. The SmartDate X40 and X45 support both intermittent and continuous motion operation. The printhead hardware is the same for both configurations — the difference is in the coder’s motion controller settings, not the printhead itself.
Q4: Is this a genuine OEM part or a compatible equivalent?
This is a 100% genuine Markem-Imaje OEM printhead bearing part number ENM10104790. It is not a third-party compatible or equivalent product. If you require a compatible alternative at a lower price point, contact us and we can advise on available options.
Q5: What ribbon should I use with this printhead?
The SmartDate X40/X45 requires TTO-formulated ribbons, typically in 55mm width. Markem-Imaje supplies dedicated TTO resin ribbons for this platform. We also supply compatible TTO ribbons — contact us for specifications matched to your film substrate (polyester, polypropylene, laminate, foil).
Q6: Do you offer volume or contract pricing?
Yes. We supply packaging line operators, maintenance contractors, and distributors globally. Contact us for pricing on standing orders and bulk purchases of 3 units or more.
Q7: How long does delivery take?
Orders ship within 1–3 business days. International delivery typically takes 3–10 business days depending on destination and customs clearance. We provide customs-ready documentation as standard.
