Product Name: Thermal Printhead
Model : Avery Dennison 6404
Category: Avery Printhead
Part Number: A0978/ A2817
Delivery Time: 1-3 days
Warranty:3 months/30km
When your Avery Dennison 6404 printer requires a new printhead, the NOVEXX A0978 / A2817 is the correct OEM replacement. This is a Near Edge thermal printhead — a technology that positions the heating element at the very edge of the print element, enabling high-speed printing with sharp dot definition. The result is consistently crisp barcodes, clean text, and accurate label output at 300 DPI resolution, even at elevated print speeds.
| Parameter | Specification |
|---|---|
| Compatible Printer | Avery Dennison 6404 (64-04) |
| OEM Part Numbers | A0978, A2817, A0978-RFL, A2817-RFL |
| Also Known As | KCE-107-12MPT2, KCE-107-12MPT2-AV |
| Print Resolution | 300 DPI (11.8 dots/mm) |
| Print Width | 106.6 mm – 160 mm |
| Print Technology | Near Edge Thermal Transfer |
| Print Method | Thermal Transfer / Direct Thermal |
| Mounting | A0978 = Left-Hand (LH) · A2817 = Right-Hand (RH) |
| Warranty | 3 months or 30 km print life |
| Delivery | 1–3 business days |
This printhead is used across multiple Avery Dennison and NOVEXX printer platforms that share the same 4-inch 300 DPI Near Edge print engine:
⚠️ A0978 vs A2817 — which one do you need?
These two part numbers refer to the same printhead in left-hand (LH) and right-hand (RH) mounting orientations. A0978 is the left-hand version fitted to the standard 6404. A2817 is the right-hand version used on ALX 734, ALX 924 (RH), and ALX 926. If you are unsure, check the label on your existing printhead or contact us — we will confirm the correct part before you order.
Near Edge technology places the heating element at the leading edge of the printhead, minimising the distance between where heat is applied and where the ribbon or label exits. This produces sharper dot edges, better barcode definition, and the ability to print at higher speeds without quality loss — critical in high-throughput logistics, manufacturing, and compliance labelling environments.
Because this is an OEM part built to the exact factory specification of the Avery Dennison 6404, installation is direct. The quick-change mounting block is included. There is no need for software recalibration or parameter adjustment after fitting — simply install, align, and resume production.
The 6404 is deployed in demanding environments: production lines, warehouses, distribution centres, and pharmaceutical labelling operations. This printhead is engineered to match those conditions — rated for continuous high-volume thermal transfer and direct thermal output across the full 106.6–160 mm print width.
Every unit is backed by a 3-month or 30-kilometre print life warranty. This reflects the OEM quality standard and gives you a clear, measurable assurance of performance from day one.
Even an OEM printhead lasts significantly longer with correct maintenance:
We ship globally with protective packaging and customs-ready documentation, typically within 1–3 business days of order confirmation. Our team has direct experience with NOVEXX and Avery Dennison printer platforms — if you are unsure whether A0978 or A2817 is the correct part for your machine, contact us before ordering and we will confirm the right unit for your configuration.
Q1: What is the difference between A0978 and A2817?
Both are 300 DPI Near Edge OEM printheads for the same 4-inch print engine. A0978 is the left-hand (LH) mounting version, fitted to the Avery Dennison 6404 / 64-04 and TTX 674. A2817 is the right-hand (RH) version for the ALX 734, ALX 924 (RH), and ALX 926. Check the orientation of your existing printhead before ordering, or contact us to confirm.
Q2: Will this printhead work on other Avery or NOVEXX models?
Yes — beyond the 6404, this printhead is used across the TTX 674, DPM4, PEM4, ALX 924, ALX 734, ALX 720, NOVEXX Chess 4, and XTP 804. These all share the same 4-inch 300 DPI Near Edge print engine. For other Avery or NOVEXX models, contact us and we will identify the correct part.
Q3: Is this a genuine OEM part?
Yes. This is a 100% original NOVEXX / Avery Dennison OEM printhead — not a compatible or third-party equivalent. It carries the original part number and is built to the factory specification.
Q4: How long will it last?
Under normal operating conditions with correct maintenance, most users achieve the full 30 km rated print life. Factors that reduce life include excessive print pressure, incompatible ribbon formulations, and infrequent cleaning. Following the maintenance steps above will help you reach and often exceed the rated life.
Q5: Do you offer volume or reseller pricing?
Yes. Contact us for pricing on orders of 5 units or more. We work with distributors, maintenance companies, and large end-users globally.
Q6: How long does delivery take?
Most orders ship within 1–3 business days. International delivery typically takes 3–10 business days depending on destination and customs clearance.
